1、webBrowser.DrawToBitmap 截图的问题

Rectangle rectangle = new Rectangle(100, 100, width, width); 所设置的偏移(100, 100),居然是内边距。这完全不是我想要的:

可以很明显的看到一些白边,这是不合理的内边距偏移导致的。

这毫无疑问是 webBrowser.DrawToBitmap 方法的设计导致的缺陷,我的解决方法是进行二次截图:

/// <summary>
/// 截取WebBrowser网页中的图片
/// </summary>
/// <param name="webBrowser">WebBrowser实例对象</param>
/// <param name="width">宽</param>
/// <param name="height">高</param>
public static void CutPic(WebBrowser w,int x = 0, int y = 0, int width = 325, int height = 413)
{
    // 全屏截图
    int full_width = w.Width;
    int full_height = w.Height;
    Bitmap bitmap = new Bitmap(full_width, full_height);
    Rectangle rectangle = new Rectangle(0, 0, full_width, full_height);
    w.DrawToBitmap(bitmap, rectangle);

    // 二次截图
    Bitmap _bitmap = new Bitmap(width, height);
    Graphics g = Graphics.FromImage(_bitmap);
    g.DrawImage(bitmap, 0, 0, new Rectangle(x, y, width, height), GraphicsUnit.Pixel);

    // 保存图片
    String Path = GetAssetsPath() + "/" + GetPicName();
    _bitmap.Save(Path);
}

果然,通过 Graphics.DrawImage 来截图时的偏移就是正常的。所以如愿以偿的从全屏图中截取到我要的图片了:


2、帮助移动端快速生成实例

http://oatest.bujidele.com:8010/ApiDoc/Help/ResourceModel?modelName=tb_car_business_after

通过网页jquery的方式:

var str = "";
$(".help-page-table tbody tr").each(function(i, e){
    var a = $(e).eq(0).find(".parameter-documentation").text().trim();
    var b = $(e).eq(0).find(".parameter-type").text().trim();
    var c = $(e).eq(0).find(".parameter-name").text().trim();
    str += "/***" + a + "***/ \r\n private " + b + " " + c + ";\r\n\r\n";
})
console.log(str);

通过sublime的方式:

^(\w+)\s(.*)\s(string|date|number|decimal|integer|boolean)

/***$2***/
 private $3 $1;

3、WebBrowser的大部分操作,几乎都需要等待DocumentCompleted完成之后才可以进行的。

/// <summary>
/// 执行函数当WebBrowser对象加载完毕时
/// MD,这个Action硬是要填入一个参数,我又不知道什么好,觉得干脆继续返回一个一模一样的WebBrowser吧,没准以后需要对它进行变化。也挺好的
/// </summary>
/// <param name="action">待执行的函数</param>
/// <param name="w">WebBrowser对象</param>
public static void ExecActionWhenWebBrowserDocumentCompleted(Action<WebBrowser> action, WebBrowser w)
{
    if (w.ReadyState == WebBrowserReadyState.Complete) {
        action(w);
    }
    else {
        // 先移除事件绑定的函数,防止重复绑定,叠加重复效果
        ClearAllEvents(w, "DocumentCompleted");
        // 绑定一个lambda表达式函数
        w.DocumentCompleted += (sender, e) => {
            action(w);
        };
    }
}

4、最常用的代码还是记录一下吧:文本框回车触发事件

if (e.KeyCode == Keys.Enter)
{
   // some code...
}
